Footnote

a 5° Forward/6° Back
b 5° Forward/9° Back
1 1 2 2 3 3 3 3 4 4 5 5 6 7 8 8 9 9 10 10 11 11 12 13 14 15 16 16 17 18

Products

* All prices are excl. VAT

No. Code Name Q1 Notes Price
No. Code Name q1 notes Price
1 1690917 CAPSCREW 2 € 7.86
2 1683473 ROD END 2 € 567.30
3 1581850 WASHER 2 € 0.89
3 1581854 WASHER 2 € 4.87
4 1690919 NUT 2 € 33.65
5 2082992 tilt cylinder (rh) 1 b € 2267.90
5 2082991 tilt cylinder (rh) 1 a € 1974.04
6 1673898 BUSHING 2 € 36.76
7 1611572 PIN 2 € 165.12
8 16001 grease fitting 4 € 1.76
9 1615240 CAPSCREW 4 € 2.50
10 1581564 LOCKWASHER 4 € 0.86
11 241079 anchor 4 € 20.74
12 1611579 BUSHING 4 € 80.44
13 1611580 SNAPRING 4 € 7.97
14 1611571 PIN 2 € 206.96
15 293730 capscrew 4 € 17.57
16 2090749 tilt cylinder (lh) 1 b € 2285.49
16 2090748 tilt cylinder (lh) 1 a € 1974.04
17 1683501 PIN 2 € 143.99
18 1690084 BUSHING 2 € 37.55
