Footnote

Q1: LH Brake
Q2: RH Brake

a Illustrated
b Not Illustrated
c RH Cover parts are located opposite those of LH Cover
1 1 1 1 2 3 3 4 5 5 6 7 8 8 9 10 10 11 12 12 13 14 15 15 16 17 17 18 19 20 21 22 22

Products

* All prices are excl. VAT

No. Code Name Q1 Q2 Notes Price
No. Code Name q1 q2 notes Price
1 1384862 PLUG 3 3 € 29.27
1 1384863 O-RING 1 1 € 2.84
2 1384864 PLUG 1 1 € 10.13
3 1384859 PLUG 1 1 € 25.47
3 1382902 O-RING 1 1 € 2.02
4 1384876 PLUG 4 4 € 337.91
5 1384878 ROD 1 1 € 52.28
5 1384881 ROLL PIN 1 1 € 0.40
6 1384884 O-RING 1 1 € 6.54
7 1384880 SPRING 1 1 € 99.57
8 1384879 SPRING GUIDE 1 1 € 87.29
9 15483 Fitting 3 3 € 2.18
10 1384883 HOUSING 1 1 € 10367.48
10 1642015 HOUSING 1 1 € 6386.61
11 1384882 SPACER 1 1 € 1561.23
12 1384873 SEPARATOR PLATE 11 11 € 308.58
13 1532251 FRICTION DISK 10 10 € 341.66
14 1384872 PISTON 1 1 € 910.86
15 1384870 SEAL 2 2 € 322.76
16 1384871 SPRING 1 1 € 16.32
17 1382902 O-RING 1 1 € 2.02
17 1384867 FITTING 1 1 € 32.33
18 15316 fitting 1 1 € 1.30
19 1384860 CAPSCREW 16 16 € 12.05
20 132451 Washer 16 16 € 1.93
21 1384861 BLEEDER SCREW 1 1 € 10.47
22 1384868 COVER 1 c € 4585.14
22 1708911 Washer 1 a € 1.79
1642014 SEAL 1 1 b € 2242.18
