Footnote

a Not Illustrated
b S/N E019E01648Z
c S/N E019E01649Z

Products

* All prices are excl. VAT

No. Code Name Q1 Notes Price
No. Code Name q1 notes Price
1 293613 capscrew 4 1.09
2 320156 washer 4 0.10
3 287854 capscrew 1 0.52
4 136692 nut 2 0.17
5 15200 Cotter Pin 1 0.13
6 1494676 screw 2 2.65
7 320160 washer 2 0.22
8 292682 lockwasher 3 0.19
9 296128 nut 1 0.87
10 292521 Capscrew 1 1.58
11 325708 Tube Assy (Pivot) 1 22.33
12 352485 Shaft 1 62.47
13 352499 Pedal (Accelerator) 1 46.27
14 352885 Rubber Pad 1 22.66
15 1558059 ROD 1 17.25
16 353142 Spring 1 8.33
17 353143 Spring 1 6.85
18 1494675 BRACKET 1 48.21
19 353164 crank 1 9.61
20 353195 Bumper 1 2.39
21 296415 Washer 2 0.86
22 2042520 CONTROLLER 1 b 9111.90
22 2051918 CONTROLLER 1 c 7010.29
23 320156 washer 1 0.10
24 1494677 SHIFTER 1 919.26
24 1494678 SHIFTER 1 1053.55
25 1529519 sensor 1 0.00
26 316834 Nut 2 0.40
27 292501 Capscrew 1 0.20
28 1506738 washer 4 0.28
1558050 bracket 1 a 101.75
15212 cotter pin 1 a 0.13
1516917 KIT-MONOTROL TO FWD/REV 1 813.47
1516919 kit-monotrol to fwd/rev lever (without autoshift) 1 1230.65
