No. Code Name Q1 Price
No. Code Name q1 Price
1 302402 locknut 1 0.87
2 320161 washer 2 0.23
3 806428 e-ring 2 0.00
3 1669105 cable assy 1 0.00
4 292527 Capscrew 1 0.95
5 129563 strap clamp 34 0.80
6 370009 Boot 1 14.52
7 1652018 PRESSURE SENDER 1 109.16
8 137852 strap clamp 21 0.15
9 1696210 WIRE HARNESS 1 6236.35
10 302400 Nut 1 0.25
11 320157 washer 4 0.10
12 153069 clamp 1 3.89
13 176640 Bolt 1 0.25
14 1696211 wire harness (hydraulics) (ffigure 4-45) 1 536.43
15 1617615 FUSE HOLDER 3 48.05
16 320156 washer 10 0.10
17 292501 Capscrew 10 0.20
18 148789 terminal 1 17.04
18 117970 battery cable AR 0.00
18 1669108 battery cable assembly 1 0.00
18 117971 terminal 1 0.00
19 148795 terminal 1 11.59
19 1669107 battery cable assembly 1 319.60
19 1357269 battery cable AR 57.17
19 117971 terminal 1 0.00
20 1617617 FUSE 2 16.66
21 1617618 FUSE 1 15.49
22 1597595 JUMPER 1 28.95
22 1354497 E-RING 1 3.36
22 806426 e-ring 1 1.35
23 1627709 JUMPER 2 24.42
23 1354497 E-RING 1 3.36
23 806426 e-ring 1 1.35
24 1698655 wire harness 1 40.59
24 806426 e-ring 2 1.35
25 4602857 label 1 0.00
25 1402923 CONNECTOR 1 23.18
25 4601412 fuse box 1 478.47
26 1608762 battery cable assembly 1 59.64
26 148795 terminal 1 11.59
26 1357269 battery cable AR 57.17
26 148792 terminal 1 20.38
27 136749 Screw 1 0.23
28 1307121 SWITCH 2 185.68
29 1459392 trim 2 0.00
30 1606425 RIVET 1 3.61
30 1616798 RIVET 10 3.71
30 4009751 panel assembly 1 0.00
31 1324517 switch (disconnect) 1 206.90
32 321158 boot 1 3.59
33 257241 Boot 2 9.23
33 4027500 BOOT 1 8.65
34 1357269 battery cable AR 57.17
34 148779 terminal 1 29.30
34 148778 terminal 1 0.00
34 1608761 BATTERY CABLE 1 75.20
35 1399332 start battery wet 2 276.86
36 1646805 link 1 263.67
37 320160 washer 1 0.22
38 302401 locknut 1 0.38
39 1691724 battery hold down 1 0.00
40 302398 locknut 2 0.10
41 320155 Washer 5 0.19
42 1585160 KIT-LOCKOUT LEVER 1 56.87
43 2044515 CAPSCREW 2 0.23
44 1668708 wire harness (rear) 1 236.66
45 2072354 CAPSCREW 1 5.45
46 1356947 BRACKET 1 7.64
47 292681 Lockwasher 1 0.14
48 136681 capscrew 1 0.23
49 927286 strap clamp 7 0.00
50 1627991 Switch (Brake Temperature) 2 194.71
