TRANSMISSION TORQUE CONVERTER HOUSING
TRANSMISSION LINES AND ATTACHING PARTS (→ S/N F117E01677G)
TRANSMISSION LINES AND ATTACHING PARTS (S/N F117E01678G →)
TRANSMISSION ASSEMBLY
TRANSMISSION PUMP DRIVE
TRANSMISSION INPUT DRIVE GEARS
TRANSMISSION TURBINE SHAFT STATOR SUPPORT AND OIL BAFFLE
TRANSMISSION CASE AND REAR COVER
TRANSMISSION SPEED SENSORS
TRANSMISSION FORWARD REVERSE AND SECOND
TRANSMISSION FORWARD CLUTCH SHAFT
TRANSMISSION REVERSE AND SECOND CLUTCH SHAFT
TRANSMISSION FIRST SPEED GEARS
TRANSMISSION FIRST SPEED SHAFT AND IDLER GEAR
TRANSMISSION FIRST SPEED CLUTCH SHAFT
TRANSMISSION THIRD SPEED GEARS
TRANSMISSION THIRD SPEED CLUTCH SHAFT
TRANSMISSION FOURTH SPEED CLUTCH SHAFT
TRANSMISSION OUTPUT SHAFT
TRANSMISSION REGULATOR VALVE AND HYDRAULIC PUMP ARRANGEMENT
TRANSMISSION TORQUE CONVERTER AND DRIVE PLATE
TRANSMISSION TORQUE CONVERTER HOUSING
TRANSMISSION CONTROL VALVE MOUNTING
TRANSMISSION CONTROL VALVE ASSEMBLY
TRANSMISSION REMOTE FILTER AND ADAPTOR
TRANSMISSION UNIVERSAL SHAFT
Register here!
Log in to your account
0
0.00
Log in to your account
0
0.00
-
1
1
2
2
2
3
4
5
5
6
7
7
7
7
7
8
9
10
11
12
12
13
14
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
30
31
31
32
32
33
33
33
33
33
33
34
34
34
34
34
34
35
36
37
38
39
40
41
6
6
6
6
37
Products
* All prices are excl. VAT
No.
Code
Name
Q1
Notes
Price
No.
Code
Name
q1
notes
Price
1
1612292
CONVERTER HOUSING
1
€
8200.27
1
1612291
CONVERTER HOUSING
1
€
15261.35
2
1612293
PLUG
3
€
7.50
3
330504
Nut
1
€
7.99
4
1612302
SLEEVE
1
€
354.16
5
330520
Washer
3
€
8.20
6
15155
lockwasher
5
€
0.14
7
16374
Capscrew
5
€
0.45
8
1612304
SLEEVE
1
€
310.83
9
1612303
SLEEVE
1
€
383.18
10
1612294
PLUG
1
€
12.47
11
1612295
O-RING
1
€
6.92
12
1389118
CLIP
2
€
9.41
13
1612298
TUBE
1
€
35.06
14
1314145
O-RING
2
€
5.99
15
1612297
TUBE
1
€
64.01
16
1612296
TUBE
1
€
89.07
17
330511
Plug
1
€
1.85
18
1612305
PLUG
2
€
6.54
19
79970
O-Ring
2
€
10.89
20
1612301
TUBE
1
€
51.60
21
1579010
SENSOR
1
€
731.92
22
1579011
o-ring
1
€
7.85
23
15316
fitting
1
€
1.30
24
330527
Breather
1
€
16.10
25
15370
Fitting
1
€
7.43
26
4027241
switch (temperature)
1
€
232.54
27
1556911
ADAPTER
1
€
75.02
28
1612305
PLUG
1
€
6.54
29
1390055
O-RING
1
€
2.01
30
14349
Fitting (Pipe Plug)
2
€
1.23
31
1612312
O-RING
3
€
9.73
32
1612311
COVER
3
€
11.43
33
1612314
LOCKWASHER
12
€
4.97
34
1612313
CAPSCREW
12
€
2.90
35
330502
Pin
2
€
6.97
36
1390038
GASKET
1
€
37.97
37
15157
lockwasher
23
€
0.61
38
1612306
CAPSCREW
14
€
9.26
39
1384794
Screw
9
€
1.91
40
1612309
SENSOR
1
€
722.97
41
1579011161232116
o-ring bracket kit-seal
1 2 1
e
€
