| 1 |
888475
|
Wire Harness (Container Handler Spreader Boom Extension 1)
|
1 |
€
2018.75
|
|
|
| 2 |
888476
|
Wire Harness (Container Handler Spreader Boom Extension 2)
|
1 |
€
2018.75
|
|
|
| 3 |
888036
|
Tube
|
1 |
€
0.00
|
|
|
| 4 |
888037
|
Tube
|
1 |
€
0.00
|
|
|
| 5 |
888038
|
Tube
|
1 |
€
0.00
|
|
|
| 6 |
888039
|
Tube
|
1 |
€
0.00
|
|
|
| 7 |
888308
|
Clamp
|
9 |
€
0.00
|
|
|
| 8 |
889149
|
Wire Harness (Attachment Indicator) (FFigure 4-14)
|
1 |
€
168.15
|
|
|
| 9 |
889041
|
Wire Harness (Attachment Indicator) (FFigure 4-15)
|
1 |
€
0.00
|
|
|
| 10 |
888111
|
Wire Harness (Standard Spreader 1) (FFigure 4-16)
|
1 |
€
820.04
|
|
|
| 11 |
888112
|
Wire Harness (Intermodal Handler) (FFigure 4-17)
|
1 |
€
0.00
|
|
|
| 12 |
888110
|
Wire Harness (Standard Spreader 2) (FFigure 4-18)
|
1 |
€
820.04
|
|
|
| 13 |
889488
|
Cable (Kruger)
|
1 |
€
0.00
|
|
|
| 14 |
888109
|
Wire Harness (Boom Light) (FFigure 4-19)
|
1 |
€
469.77
|
|
|
| 15 |
302024
|
Screw (With Sliding Cab)
|
4 |
€
0.59
|
|
|
| 16 |
292667
|
nut
|
4 |
€
0.14
|
|
|
| 17 |
292678
|
Lockwasher
|
4 |
€
0.12
|
|
|
| 18 |
1384603
|
Brake/Backup Light (Brake and Back-Up)
|
2 |
€
0.00
|
|
|
| 19 |
887277
|
Bracket (LH Rear)
|
1 |
€
0.00
|
|
|
| 20 |
292668
|
Nut
|
4 |
€
0.10
|
|
|
| 21 |
292679
|
washer
|
4 |
€
0.12
|
|
|
| 22 |
887307
|
Light
|
6 |
€
164.98
|
|
|
| 23 |
1310668
|
BULB
|
6 |
€
12.00
|
|
|
| 24 |
888343
|
Sealing Ring
|
1 |
€
0.00
|
|
|
| 25 |
889196
|
Switch (Temperature Sender)
|
1 |
€
209.26
|
|
|
| 26 |
1388287
|
SENSOR
|
1 |
€
739.60
|
|
|
| 27 |
1314149
|
O-RING
|
2 |
€
1.74
|
|
|
| 28 |
1367282
|
BACK-UP ALARM
|
1 |
€
341.65
|
|
|
| 29 |
136749
|
Screw
|
2 |
€
0.23
|
|
|
| 30 |
320157
|
washer
|
2 |
€
0.10
|
|
|
| 31 |
292681
|
Lockwasher
|
2 |
€
0.14
|
|
|
| 32 |
239503
|
nut
|
2 |
€
0.13
|
|
|
| 33 |
391484
|
Clamp (Insulated)
|
5 |
€
33.50
|
|
|
| 34 |
889362
|
Switch (Water Level)
|
1 |
€
575.76
|
|
|
| 35 |
1388286
|
SENSOR
|
1 |
€
598.55
|
|
|
| 36 |
888337
|
Switch
|
1 |
€
163.53
|
|
|
| 37 |
888221
|
Adapter
|
1 |
€
108.39
|
|
|
| 38 |
1311398
|
PRESSURE SWITCH
|
1 |
€
107.06
|
|
|
| 39 |
292514
|
capscrew
|
2 |
€
0.48
|
|
|
| 40 |
388049292682
|
Lockwasher
|
2 |
€
0.00
|
|
|
| 41 |
886215
|
Pressure Switch
|
1 |
€
239.72
|
|
|
| 42 |
887328
|
Pressure Sender
|
1 |
€
433.61
|
|
|
| 43 |
16187
|
Fitting
|
2 |
€
4.46
|
|
|
| 44 |
886213
|
Switch (Battery Cut-off)
|
1 |
€
0.00
|
|
|
| 45 |
888249
|
Battery Cable
|
1 |
€
0.00
|
|
|
| 46 |
257241
|
Boot
|
2 |
€
9.23
|
|
|
| 47 |
887348
|
Battery Cable (-)
|
1 |
€
0.00
|
|
|
| 48 |
888248
|
Battery Cable
|
1 |
€
0.00
|
|
|
| 49 |
888448
|
Battery Cable
|
1 |
€
0.00
|
|
|
| 50 |
887347
|
Battery Cable (+)
|
1 |
€
0.00
|
|
|
| 51 |
887346
|
Start Battery Wet
|
2 |
€
0.00
|
|
|
| 52 |
136692
|
nut
|
2 |
€
0.17
|
|
|
| 53 |
885687
|
Link (Battery Hold Down)
|
4 |
€
0.00
|
|
|
| 54 |
885688
|
Clamp (Battery Hold Down)
|
2 |
€
0.00
|
|
|
| 55 |
310101
|
Nut
|
4 |
€
3.08
|
|
|
| 56 |
888114
|
Wire Harness (Rear Lights Back-Up Alarm and Fuel Level) (FFigure 4-20)
|
1 |
€
792.18
|
|
|
| 57 |
292681
|
Lockwasher
|
2 |
€
0.14
|
|
|
| 59 |
888209
|
Control Box
|
1 |
€
0.00
|
|
|
| 60 |
888320
|
Sensor
|
1 |
€
805.51
|
|
|
| 61 |
888321
|
Gasket
|
1 |
€
35.04
|
|
|
| 62 |
292500
|
Capscrew
|
6 |
€
0.16
|
|
|
| 63 |
292680
|
Washer
|
6 |
€
0.10
|
|
|
| 64 |
888108
|
Wire Harness (Engine Compartment) (FFigure 4-22)
|
1 |
€
817.59
|
|
|
| 65 |
888107
|
Wire Harness (Front Lights and Kruger Device) (FFigure 4-23)
|
1 |
€
768.65
|
|
|
| 66 |
888147
|
Wire Harness (Transmission Control) (FFigure 4-25)
|
1 |
€
560.81
|
|
|
| 67 |
888113
|
Wire Harness (LH) (FFigure 4-27)
|
1 |
€
905.45
|
|
|
| 68 |
888116
|
Wire Harness (RH) (FFigure 4-29)
|
1 |
€
365.33
|
|
|
| 58 |
239503
|
nut
|
4 |
€
0.13
|
|
|
