Footnote

a Not Illustrated
b → S/N A222E01611C
c S/N A222E01612C →

Products

* All prices are excl. VAT

No. Code Name Notes Price
No. Code Name notes Price
1 1587599 Housing 305.51
2 0.00
3 1515852 CLAMP 123.64
4 1515853 Housing 0.00
5 1513324 PLATE 45.59
6 1513318 Screw 4.81
7 1515854 CLAMP 127.52
8 1515855 NUT 8.75
9 1513333 SEALING RING 16.22
10 1587600 HOUSING 298.42
11 1513323 Baffle 14.36
12 1515856 BEARING 37.44
13 1513327 HEAT SHIELD 22.15
14 1515857 SEALING RING 42.11
15 1515858 RETAINING RING 8.70
16 1539268 THRUST BEARING 60.69
17 1513331 Retaining Ring 33.92
18 1513336 O-Ring 28.15
19 1513335 Locknut 15.48
20 1515859 SLINGER 102.46
21 1587601 IMPELLER 460.28
22 1515860 SHAFT 624.13
23 1515861 Collar 36.38
24 1515862 GASKET 28.54
25 1513435 GASKET 4.73
26 1512588 O-RING 6.54
27 1513338 NUT 7.87
28 1515863 STUD 36.99
1515912 CLAMP a 130.51
1515850 Turbocharger b 6219.42
1587597 Kit-Repair Turbocharger c 5898.78
