Footnote

a Not Illustrated
b 4/2001
c S/N F007E01976Z
d S/N F007E02660A
e S/N F007E01977Z ↔ S/N F007E02660A
f S/N F007E01977Z
g S/N F007E02661A

Products

* All prices are excl. VAT

No. Code Name Q1 Notes Price
No. Code Name q1 notes Price
1 1516686 condenser 1 e 0.00
1 1538218 CONDENSER 1 g 2973.25
1 1501238 condenser 1 d 0.00
2 320157 washer 1 0.10
3 292681 Lockwasher 1 0.14
4 176640 Bolt 4 0.25
5 1485957 HOSE ASSY 1 190.02
6 1487118 O-RING 4 2.18
7 1486637 PRESSURE SWITCH 1 b 162.39
8 303493 grommet 3 7.62
9 358354 hose 1 0.00
10 255578 clamp 1 8.96
11 153069 clamp 1 3.89
12 239503 nut 1 0.13
13 1487122 o-ring 2 3.77
14 129563 strap clamp 6 0.80
15 1485956 HOSE ASSY 1 206.48
16 1485954 hose assy 1 360.49
17 1487125 O-RING 2 2.65
18 320159 washer 10 0.13
19 292682 lockwasher 7 0.19
20 287854 capscrew 5 0.52
21 1390281 CAPSCREW 1 10.50
22 287860 Capscrew 1 0.65
23 1480318 COMPRESSOR 1 1829.31
24 1480322 bracket 1 c 0.00
24 1510210 BRACKET WLDMT 1 f 351.03
25 136692 nut 3 0.17
26 1485960 heat shield 1 0.00
27 114310 hose 1 0.00
28 199337 hose assy 1 0.00
29 320158 washer 2 0.45
30 270849 hose 1 0.00
31 1485953 HOSE ASSY 1 162.93
32 132861 Capscrew 1 0.38
33 132796 clamp 2 0.00
34 385107 Clamp (Insulated) 1 8.03
35 1475025 AIR DRYER 1 205.15
