Footnote

Q1. Manual Tilt
Q2. Power Tilt

Products

* All prices are excl. VAT

No. Code Name Q1 Q2 Price
No. Code Name q1 q2 Price
1 2043194 TILT CYLINDER 1 € 778.46
2 1486535 PUMP 1 € 516.03
3 1487204 HANDLE 1 € 35.95
4 136692 nut 1 1 € 0.17
5 370776 switch 1 € 29.55
6 1474921 SHAFT 1 € 174.32
7 1496296 FITTING 1 1 € 18.14
8 1480187 CONNECTOR 1 € 16.79
8 1484709 Terminal (Pin) 2 € 0.00
8 1 € 0.00
8 1480188 CONNECTOR LOCK 1 € 0.91
8 1475732 CAB TILT PUMP 1 € 1417.85
9 1485271 BRACKET 1 € 435.40
10 1486540 MOUNT 4 4 € 64.44
11 2049849 WIRE HARNESS 1 € 86.97
12 1486630 PIN 1 1 € 83.23
13 320169 Washer 1 1 € 1.55
14 15235 cotter pin 2 2 € 0.42
15 292681 Lockwasher 8 2 € 0.14
16 287851 capscrew 2 2 € 0.23
18 292514 capscrew 2 2 € 0.48
19 300939 Washer 4 4 € 4.71
20 296382 washer 4 4 € 0.25
21 292535 Capscrew 4 4 € 1.87
22 1486539 LATCH 2 2 € 361.77
23 195566 anchor 1 1 € 17.97
24 1520841 SHIM 2 2 € 3.34
25 1486067 HOSE ASSY 1 1 € 71.63
26 1486068 HOSE ASSY 1 1 € 55.35
27 1486069 HOSE ASSY 1 1 € 125.14
28 1486070 HOSE ASSY 1 1 € 120.40
29 320157 washer 8 8 € 0.10
30 176640 Bolt 7 7 € 0.25
31 136749 Screw 1 1 € 0.23
32 239503 nut 7 7 € 0.13
33 1496296 FITTING 1 1 € 18.14
34 1488675 FITTING 1 1 € 13.47
35 1488676 FITTING 2 2 € 10.87
36 292517 Capscrew 1 1 € 0.93
37 1486825 TILT PLATFORM 1 € 2557.48
37 1493322 ADHESIVE AR AR € 49.98
38 1493379 frame 1 1 € 0.00
39 1493380 BEARING 2 2 € 16.75
40 1493381 ROD 1 1 € 223.11
41 1493382 CATCH 1 1 € 138.19
42 1493383 KNOB 1 1 € 20.48
43 1493384 RETAINING RING 1 1 € 9.09
44 1493385 SPRING 1 1 € 10.04
45 1493386 WASHER 2 2 € 0.31
46 1493387 COTTER PIN 1 1 € 5.75
47 2004005 STRAP CLAMP 1 € 0.65
48 1496459 FITTING 1 € 17.69
49 1496368 HOSE ASSY 1 € 60.64
50 137852 strap clamp 1 € 0.15
51 397676 strap clamp AR AR € 0.95
17 292682 lockwasher 3 3 € 0.19
