Footnote

Q1. Right Hand
Q2. Left Hand

a Included with 1510214 and 1510213

Products

* All prices are excl. VAT

No. Code Name Q1 Q2 Notes Price
No. Code Name q1 q2 notes Price
1 1510214 door (glass) 1 € 0.00
1 1510213 door (glass) 1 € 0.00
2 1495441 SEAL AR AR € 21.15
3 1542548 SHIM 1 1 € 3.43
3 1495442 SLIDING WINDOW 1 1 a € 375.99
3 1542549 screw 2 2 € 0.00
3 1483226 LATCH 1 1 € 60.21
3 1542547 plate 1 1 € 0.00
4 1495464 frame 1 € 0.00
4 1495443 frame 1 € 0.00
5 1495444 GASKET 1 € 15.07
5 1495465 gasket 1 € 0.00
6 1497240 HINGE 1 € 131.36
6 1495446 HINGE 1 € 131.42
7 1495447 washer 4 4 € 0.00
8 1495448 washer 4 4 € 0.00
9 1495449 bushing 4 4 € 9.50
10 1495450 washer 2 2 € 0.00
11 1495451 screw 1 1 € 0.00
12 1495452 SCREW 3 3 € 3.28
13 320160 washer 4 4 € 0.22
14 1493501 nut 4 4 € 0.00
15 1493312 CAP 4 4 € 0.58
16 1495453 LATCH 1 € 94.71
16 1497241 LATCH 1 € 54.49
17 1495456 washer 1 1 € 12.10
18 1495454 SEAL 1 1 € 3.56
19 1495455 screw 3 3 € 0.00
20 316834 Nut 3 3 € 0.40
21 320156 washer 3 3 € 0.10
22 1493397 COVER 3 3 € 0.60
23 1495434 LATCH 1 € 224.81
23 1495437 LATCH 1 € 219.10
24 1495435 COVER 1 € 16.28
24 1495438 COVER 1 € 15.72
25 296229 capscrew 2 2 € 2.41
26 1495459 bushing 1 1 € 0.00
27 1495460 bushing 1 1 € 7.70
28 1495462 bolt 2 2 € 14.79
29 1495463 washer 2 2 € 3.23
30 1468316 WASHER 1 1 € 0.63
31 1507006 key 1 1 € 0.00
31 1495371 HANDLE 1 1 € 150.79
32 1495372 SEAL 1 1 € 6.20
33 1495431 SEAL 1 1 € 5.22
34 1495432 bolt 1 1 € 0.00
35 1468321 washer (plastic) 1 1 € 1.10
36 1493397 COVER 1 1 € 0.60
1495436 latch 1 € 300.45
1495439 latch 1 € 355.05
1495433 handle 1 1 € 250.24
1495465 gasket 1 € 0.00
