Footnote

Q1.Right Hand
Q2.Left Hand

a Not Illustrated

Products

* All prices are excl. VAT

No. Code Name Q1 Q2 Notes Price
No. Code Name q1 q2 notes Price
1 1515337 SEAL AR AR € 26.11
1 1506798 frame 1 € 0.00
1 1506803 frame 1 € 0.00
2 1506804 SLIDING WINDOW 1 € 1442.43
2 1506799 SLIDING WINDOW 1 € 1442.45
3 1393476 ACTIVATOR 4 4 € 131.89
4 1393477 PRIMER AR AR € 171.54
6 1506800 WINDOW 1 1 € 189.57
7 1506801 terminal AR AR € 0.00
8 1393466 SEAL 1 1 € 2.44
9 1506802 cover plate (door) 1 € 0.00
9 1506805 cover plate (door) 1 € 0.00
10 287854 capscrew 1 1 € 0.52
11 320160 washer 2 2 € 0.22
12 1493501 nut 1 1 € 0.00
13 1493312 CAP 2 2 € 0.58
14 1495453 LATCH 1 € 94.71
14 1497241 LATCH 1 € 54.49
15 1495456 washer 1 1 € 12.10
16 1495454 SEAL 1 1 € 3.56
17 1495432 bolt 3 3 € 0.00
18 320156 washer 3 3 € 0.10
20 1495434 LATCH 1 € 224.81
20 1495437 LATCH 1 € 219.10
21 1495435 COVER 1 € 16.28
21 1495438 COVER 1 € 15.72
22 296229 capscrew 2 2 € 2.41
27 1495371 HANDLE 1 1 € 150.79
28 1495372 SEAL 1 1 € 6.20
29 1495431 SEAL 1 1 € 5.22
30 1495432 bolt 1 1 € 0.00
31 1468321 washer (plastic) 1 1 € 1.10
1393475 adhesive AR AR a € 0.00
1507006 key 1 1 a € 0.00
1495459 bushing 1 1 a € 0.00
1495460 bushing 1 1 a € 7.70
1495462 bolt 2 2 a € 14.79
1495463 washer 2 2 a € 3.23
1495433 handle 1 1 € 250.24
1495436 latch 1 € 300.45
1495439 latch 1 € 355.05
1498750 kit-seal 1 1 € 97.00
