Footnote

Q1.1501238 (Standard)
Q2.1516686 (Tropical)
Q3.1538218 (Standard)

a S/N F007E02660
b S/N F007E01977 ↔ S/N F007E02660
c S/N F007E02661
1 1 2 2 3 4 4 4 5 5 5 5 5 5 6 7 8 8 8 9 9 10 11 12 13

Products

* All prices are excl. VAT

No. Code Name Q2 Q1 Q3 Price
No. Code Name q2 q1 q3 Price
1 1564437 housing 1 € 0.00
1 1496868 housing 1 € 0.00
2 1564436 cover 1 € 568.59
2 1496867 cover 1 € 0.00
3 1496866 plate (fan) 1 € 0.00
4 1564434 coil (condenser) 1 € 916.00
4 1550921 CORE 1 € 964.80
4 1496865 COIL 1 € 648.57
5 1496864 FAN 2 € 386.47
5 1564433 FAN 2 € 444.36
5 1550923 FAN 2 € 458.03
6 1496863 hose clamp 1 € 0.00
7 1496862 hose clamp 1 € 0.00
8 1514711 wire harness 1 € 0.00
8 1564432 wire harness 1 € 0.00
8 1550924 WIRE HARNESS 1 € 379.25
9 1514712 PRESSURE SWITCH 1 1 € 213.71
9 1550922 PRESSURE SWITCH 1 € 183.58
10 1496801 resistor 1 1 € 0.00
11 1496800 RELAY 2 2 € 43.25
12 1499057 washer 8 € 0.00
13 1499058 nut 4 € 0.00
