Footnote

a → 6/2007
b → S/N F019E02046C
c → S/N F019E02143D
d S/N F019E02047C ↔ 6/2007
e S/N F019E02047C →
f S/N F019E02144D →
g 6/2007 →

Products

* All prices are excl. VAT

No. Code Name Q1 Notes Price
No. Code Name q1 notes Price
1 1485958 HOSE ASSY 1 177.10
2 303493 grommet 3 b 7.62
3 1487118 O-RING 4 a 2.18
4 1538218 CONDENSER 1 a 2973.25
4 1654661 CONDENSER 1 g 3128.37
5 1538217 AIR DRYER 1 a 204.10
5 1654662 AIR DRYER 1 g 359.33
6 292681 Lockwasher 4 0.14
7 1591591 BRACKET 1 33.67
8 2097620 V-BELT 1 e 14.96
8 2046918 v-belt 1 b 0.00
9 1500869 PULLEY 1 98.01
10 1500871 BRACKET 1 780.17
11 15134 Washer 3 0.42
12 220159 Capscrew 3 3.83
13 16816 capscrew 3 1.30
14 1359458 CAPSCREW 2 3.79
15 320159 washer 6 0.13
16 1623950 bracket 2 e 46.84
16 1500870 BRACKET 2 b 161.81
17 1373791 SPACER 2 32.76
18 292682 lockwasher 6 0.19
19 136692 nut 6 0.17
20 1605597 WIRE 1 18.71
21 287860 Capscrew 4 0.65
22 1487122 o-ring 2 a 3.77
23 1514338 HOSE ASSY 1 181.40
24 1610764 HOSE ASSY 1 b 272.88
24 1624089 HOSE ASSY 1 d 269.06
24 1656591 hose assy 1 g 270.50
25 1487125 O-RING 2 a 2.65
26 1480318 COMPRESSOR 1 1829.31
27 239503 nut 1 0.13
28 292681 Lockwasher 1 0.14
29 320157 washer 6 0.10
30 176640 Bolt 5 0.25
31 1316496 CLAMP 1 8.94
32 166857 Clamp 2 c 2.37
32 1502005 HOSE CLAMP 2 f 3.13
33 199337 hose assy 1 0.00
34 114310 hose 1 0.00
35 129563 strap clamp 9 0.80
36 1485953 HOSE ASSY 1 a 162.93
36 1656585 HOSE ASSY 1 g 254.75
