Footnote

a Not Illustrated
b → S/N F019E02046C
c S/N F019E02047C →

Products

* All prices are excl. VAT

No. Code Name Q1 Notes Price
No. Code Name q1 notes Price
1 362030 Handle 2 7.39
2 1477508 BRACKET 1 731.40
3 292501 Capscrew 4 0.20
4 320156 washer 4 0.10
5 292680 Washer 4 0.10
6 136687 nut 4 0.10
7 292528 capscrew 4 0.95
8 1479870 SCREW 4 19.42
9 136692 nut 4 0.17
10 320157 washer 2 0.10
11 292681 Lockwasher 4 0.14
12 1489092 SCREW 2 21.34
13 216877 nut 10 0.27
14 239503 nut 4 0.13
15 376397 retainer 2 2.89
16 18498 capscrew 2 1.10
17 1479871 WASHER 2 14.75
18 292535 Capscrew AR 1.87
19 300088 seal 8 13.28
20 320162 Washer 8 0.54
21 292683 Lockwasher 10 0.16
22 1554208 ENGINE COVER 1 2983.18
23 1476910 HOOD 1 1988.96
24 1385584 GAS SPRING 2 145.54
25 1476911 HOOD 1 1988.96
26 1478959 ROD 2 259.06
27 1489401 support 1 0.00
28 1477512 BRACKET 1 301.04
29 2043079 PLUG 4 c 2.75
29 1494868 PLUG 4 b 0.80
30 1613498 PLUG 4 c 4.55
30 1494869 plug (without air conditioner) 3 b 1.85
31 1382332 LATCH 2 102.02
32 1494480 PLATE 2 268.17
33 320155 Washer 4 0.19
34 296155 Capscrew 4 1.25
35 292679 washer 4 0.12
36 292668 Nut 4 0.10
37 320160 washer 4 0.22
38 292682 lockwasher 4 0.19
39 136692 nut 4 1 a 0.17
41 309666 plug 2 1.18
42 1494642 SHIM AR 40.16
42 1494643 SHIM AR 23.16
42 1494645 shim AR 42.31
43 320158 washer AR 0.45
44 1587730 sound liner (lh) (eec) 1 134.53
45 1587731 sound liner (rh) (eec) 1 134.53
46 1587727 SOUND LINER 1 46.09
47 1587726 SOUND LINER 1 63.38
48 1587734 sound liner (lh) (eec) 1 96.56
49 1587735 sound liner (rh) (eec) 1 96.56
50 1498373 PLATE 28 6.16
51 136985 capscrew 28 0.65
52 1593327 SPACER 28 5.54
1606784 Plug 11 a 0.52
