Footnote

a Not Illustrated
b → S/N F019E02346D
c S/N F019E02347D →

Products

* All prices are excl. VAT

No. Code Name Q1 Notes Price
No. Code Name q1 notes Price
1 1506751 SUNSHADE 1 € 563.24
2 1655365 SCREW 2 € 1.96
3 1506749 RUBBER PAD 1 € 3.24
4 1493322 ADHESIVE AR € 49.98
5 1506750 CLAMP 1 € 149.20
6 1506748 RUBBER PAD 1 € 3.24
7 1468318 SCREW 2 € 1.08
8 1539034 NUT 2 € 0.83
9 1312226 Fan Assembly 1 € 391.38
9 1307755 FAN 1 € 216.74
9 181045 Connector Body 1 € 1.61
9 1480217 fan 1 € 0.00
10 1468319 SCREW 4 € 1.08
11 1516559 BULB 1 € 19.76
11 1506682 MAP LIGHT 1 € 180.78
12 1468318 SCREW 2 € 1.08
13 287854 capscrew 2 € 0.52
14 1520841 SHIM 1 € 3.34
15 1491020 ROD 1 € 15.17
16 1491016 INCHING PEDAL 1 € 188.54
17 1520596 COVER 2 € 46.94
18 1492224 bearing 2 € 0.00
19 15201 cotter pin 2 € 0.10
20 320156 washer 2 € 0.10
21 239503 nut 4 € 0.13
22 1492225 BEARING 2 € 37.52
23 320158 washer 8 € 0.45
24 287851 capscrew 4 € 0.23
25 1483425 HORN 1 € 93.06
26 1492221 NUT 2 € 1.32
27 374159 Switch ... 1 € 19.28
28 302014 Screw .... 2 € 0.86
29 1493377 PLATE 1 € 46.94
30 2055720 capscrew 5 € 0.38
31 1492233 cover 1 € 29.61
32 1498371 INSULATION 1 € 223.15
33 1648559 INSULATION 1 € 249.00
34 1567942 INSULATION 1 € 138.81
35 1498372 INSULATION 1 € 157.19
36 1498373 PLATE 20 € 6.16
37 320160 washer 20 € 0.22
38 292514 capscrew 20 € 0.48
39 340213 Capscrew 1 € 23.35
40 1491015 SHAFT 1 € 351.48
41 1570557 sunshade (rear) 1 € 0.00
42 1468318 SCREW 3 € 1.08
43 1644793 Plug 2 € 0.00
44 1655365 SCREW 2 € 1.96
45 1644792 BRACKET 1 € 28.17
46 1506748 RUBBER PAD 2 € 3.24
47 1506749 RUBBER PAD 1 € 3.24
48 1468318 SCREW 1 € 1.08
49 296415 Washer 1 € 0.86
50 1644791 BRACKET 1 € 144.65
51 1623364 CAPSCREW 4 € 0.94
52 296419 washer 4 € 0.98
53 1468313 NUT 4 € 0.54
1492214 wire (ground) 1 a € 56.75
1 ab € 0.00
2088035 Wire Harness (Cab Underfloor) 1 ac € 562.72
1492229 Plate (Inching Pedal) 1 a € 39.24
313860 Flange 2 a € 4.77
292501 Capscrew 2 a € 0.20
316834 Nut 2 a € 0.40
1648560 INSULATION 1 a € 138.32
1648561 INSULATION 1 a € 138.32
1498387 Spring ... 1 a € 0.00
1569801 SENSOR 1 ab € 1208.18
2076661 SENSOR 1 ac € 998.95
70 4001209 SPRING 1 € 11.59
