Footnote

Q1. Fabric Cover
Q2. Vinyl Cover

a Not Illustrated
1 1 1 1 1 1 1 1 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 3 3 3 3 3 3 4 4 4 4 4 4 4 5 5 5 5 5 5 6 6 6 6 6 6 7 7 7 7 7 7 7 7 7 7 8 8 8 8 8 8 8 8 9 9 9 9 9 9 9 9 9 9 9 10 10 10 10 10 10 10 10 11 11 11 11 11 12 12 12 12 12 12 12 12 13 14 15 16 17 7 8 8

Products

* All prices are excl. VAT

No. Code Name Q1 Q2 Price
No. Code Name q1 q2 Price
1 1482952 CLIP 2 2 € 1.96
1 1482919 Locknut 2 2 € 8.00
1 1482924 Screw 2 2 € 2.21
1 1482953 STRAP CLAMP 1 1 € 7.93
1 1482951 Bolt 1 1 € 8.66
1 1482974 KIT-BRACKET 1 1 € 139.51
1 1482917 Locknut 3 3 € 1.44
1 1482806 Bracket 1 1 € 0.00
2 1615147 KIT-BACK/HEADREST CUSHIO 1 € 119.53
2 1615149 guide assembly 2 € 80.78
2 1615150 KIT-BACK/HEADREST CUSHIO 1 € 194.12
2 1574082 Headrest 1 € 0.00
2 1574081 cushion 1 € 84.33
3 1 € 0.00
3 1482924 Screw 2 € 2.21
3 1482958 SEAT CUSHION 1 € 231.16
3 1482955 seat cushion 1 € 127.05
3 1482957 KIT-SEAT CUSHION 1 € 156.28
4 1482959 PAN 1 1 € 372.72
4 1482917 Locknut 8 8 € 1.44
4 1482919 Locknut 2 2 € 8.00
4 1482924 Screw 2 2 € 2.21
4 1615057 Bolt 1 1 € 5.90
4 1482913 Connector 6 6 € 0.00
4 1615056 Pan 1 1 € 74.54
5 1482961 Screw 1 1 € 5.16
5 292528 capscrew 1 1 € 0.95
5 1482960 ARMREST 1 1 € 151.44
5 1482920 Washer 2 2 € 1.51
5 1482919 Locknut 1 1 € 8.00
5 1482804 Armrest 1 1 € 0.00
6 1470155 information case 1 1 € 96.37
6 1482948 BOX 1 1 € 27.62
6 1482949 screw 4 4 € 7.83
6 1482950 COVER 1 1 € 17.92
6 1482925 Plate (Book Box) 1 1 € 0.00
6 1467522 Information Case 1 1 € 0.00
7 1482969 Kit-Bracket (LH) 1 1 € 129.56
7 1615057 Bolt 1 1 € 5.90
7 1482919 Locknut 2 2 € 8.00
7 1482961 Screw 1 1 € 5.16
7 1482952 CLIP 2 2 € 1.96
7 1482924 Screw 2 2 € 2.21
7 1482953 STRAP CLAMP 1 1 € 7.93
7 1482917 Locknut 3 3 € 1.44
7 1482910 Nut 1 1 € 0.00
7 1482805 Bracket 1 1 € 0.00
7 292528 capscrew 1 1 € 0.95
8 1615064 spacer 2 2 € 5.94
8 1615062 KIT-SEAT BELT 1 1 € 137.16
8 1615063 Washer 3 3 € 6.01
8 246001 Capscrew 1 1 € 1.04
8 292528 capscrew 1 1 € 0.95
9 1482970 KIT-RECLINER 1 1 € 132.45
9 1482909 Spring 1 1 € 0.00
9 1482917 Locknut 5 5 € 1.44
9 1615057 Bolt 1 1 € 5.90
9 1482907 Cover 1 1 € 0.00
9 1482906 Latch 1 1 € 0.00
9 1482908 Spring 1 1 € 0.00
9 1482904 Lever 1 1 € 0.00
9 1467531 KNOB 1 1 € 15.63
9 1482905 Plate 1 1 € 0.00
9 1482919 Locknut 2 2 € 8.00
10 1615057 Bolt 2 2 € 5.90
10 1482801 Seat Pan 1 1 € 119.81
10 1482952 CLIP 2 2 € 1.96
10 1482919 Locknut 2 2 € 8.00
10 1482953 STRAP CLAMP 1 1 € 7.93
10 1482951 Bolt 6 6 € 8.66
10 1482971 KIT-SEAT PAN 1 1 € 230.81
10 1482917 Locknut 12 12 € 1.44
11 1615066 KIT-OPERATOR PRESENCE SY 1 1 € 97.30
11 1482953 STRAP CLAMP 2 2 € 7.93
11 1615068 WIRE HARNESS 1 1 € 55.15
11 1482952 CLIP 2 2 € 1.96
11 1615067 SWITCH 1 1 € 49.55
12 1482956 seat cushion 1 € 0.00
12 1615158 KIT-SEAT CUSHION 1 € 148.62
12 1615055 SEAT CUSHION 1 € 215.25
12 1482953 STRAP CLAMP 1 € 7.93
12 1482952 CLIP 2 € 1.96
12 1482803 Seat Cushion 1 € 0.00
13 1558035 LOCKWASHER 4 4 € 1.13
14 1 1 € 0.00
15 1 1 € 0.00
16 1476584 COVER 4 4 € 0.58
17 136681 capscrew 4 4 € 0.23
1561530 capscrew 1 € 0.00
1615152 KIT-CUSHION 1 € 461.66
