Q1. 6KM 1986 Series Motor
Q2. 7KM 1987 Series Motor
Q3. 8KM 1988 Series Motor
Q4. 9KM 1989 Series Motor

a → S/N F006A10107
b S/N F006A10108 →

Products

* All prices are excl. VAT

No. Code Name Q1 Q2 Q3 Q4 Notes Price
No. Code Name q1 q2 q3 q4 notes Price
1 388372 piston (0,76 mm) 6 6 6 6 € 0.00
1 306772 piston (standard) 6 € 0.00
1 388371 piston (0,13 mm) 6 6 € 0.00
1 1374309 PISTON AND ROD 6 6 6 € 158.35
2 375550 kit-piston ring (0,762 mm o/s) 6 6 6 6 € 0.00
2 306774 kit-piston ring 6 6 6 6 € 50.81
3 375577 rod 6 6 6 6 € 0.00
4 1360182 BOLT 2 2 2 2 € 12.06
5 221708 nut 2 2 2 2 € 0.87
6 301957 bushing (position c) 1 1 1 1 € 0.00
7 301956 bushing (position b) 2 2 2 2 € 0.00
8 263788 plug 1 1 1 1 € 0.00
9 375613 camshaft 1 € 0.00
9 388354 camshaft 1 1 1 € 0.00
10 1450941 PIN 1 1 1 1 € 16.50
11 1335057 key 2 2 2 2 € 12.86
12 375551 kit-crankshaft bearing 1 1 1 1 € 46.94
12 1324015 crankshaft bearing (0,25 mm) 1 1 1 1 € 0.00
12 1324016 bearing (0,51 mm) 1 1 1 1 € 0.00
12 1324018 bearing (1,02 mm) 1 1 1 1 € 0.00
12 1324017 CRANKSHAFT BEARING 1 1 1 1 € 64.84
13 263759 crankshaft bearing (0,51 mm) 1 1 € 0.00
13 263758 crankshaft bearing (0,25 mm) 1 1 € 0.00
13 263755 crankshaft bearing (0,03 mm) 1 1 € 0.00
14 1324012 bearing (0,51 mm) 6 6 6 6 € 0.00
14 375579 bearing (standard) 6 6 6 6 € 0.00
14 1324011 PISTON ROD BEARING 6 6 6 6 € 19.26
14 1324013 bearing (0,76 mm) 6 6 6 6 € 0.00
14 1324014 bearing (1,02 mm) 6 € 0.00
15 375575 bolt 2 2 2 2 € 15.18
16 1335490 BOLT 1 1 1 1 € 7.52
17 350152 flywheel (ffigure 2-3) 1 1 1 1 a € 0.00
17 350153 flywheel (ffigure 2-3) 1 1 1 1 € 0.00
17 1459400 FLYWHEEL 1 1 1 1 b € 545.05
18 375582 gasket 1 1 1 1 € 105.39
19 1306676 OIL PAN 1 1 1 1 € 295.88
20 388305 gasket 1 1 1 € 7.06
20 164029 screw 1 1 1 1 € 0.00
21 16378 Capscrew 12 12 12 12 € 0.23
22 375584 nut 4 4 4 4 € 0.00
23 375574 stud 2 2 2 2 € 0.00
24 388313 nut 1 1 1 € 3.69
24 370156 nut 1 € 0.00
25 375572 retainer 1 1 1 1 € 200.35
26 375574 stud 1 2 2 2 € 0.00
27 1335228 SEAL 1 1 1 1 € 118.58
28 1500884 GASKET 1 1 1 1 € 8.06
29 375570 crankshaft 1 1 1 1 € 0.00
30 375571 pin 1 1 1 1 € 4.71
31 375601 pin 1 1 1 1 € 2.67
32 1 1 1 1 € 0.00
33 263789 cap 3 3 3 3 € 0.00
34 263842 bolt 8 8 8 8 € 12.70
35 388310 sprocket 1 1 1 € 0.00
35 375615 sprocket 1 € 106.34
36 375576 damper 1 € 0.00
36 1339967 DAMPER 1 1 1 € 465.88
37 221455 capscrew 3 3 € 5.42
37 242164 washer 3 3 3 3 € 1.51
37 221453 capscrew 3 3 € 0.38
38 1339974 SPROCKET 1 1 € 108.34
38 375614 sprocket 1 € 0.00
38 388309 sprocket 1 € 0.00
39 388355 chain 1 1 1 € 0.00
39 375616 chain 1 € 87.68
41 1 1 1 1 € 0.00
42 221549 capscrew 1 1 1 1 € 1.47
43 16634 capscrew 3 3 3 3 € 1.07
43 220159 Capscrew 3 3 3 3 € 3.83
44 301955 bushing (position a d) 1 1 1 1 € 0.00
306770 cylinder block 1 1 1 1 € 0.00
1303792 cylinder block 1 1 1 1 € 0.00
