Footnote

Q1. 6KM 1986 Series Motor
Q2. 7KM 1987 Series Motor
Q3. 8KM 1988 Series Motor
Q4. 9KM 1989 Series Motor

a S/N F006A05278

Products

* All prices are excl. VAT

No. Code Name Q1 Q2 Q3 Q4 Notes Price
No. Code Name q1 q2 q3 q4 notes Price
1 375620 gasket 2 2 2 2 € 32.11
2 1334422 cover (rh) 1 1 1 1 € 0.00
2 375617 cover 1 1 1 1 € 116.27
3 1314274 CAP 1 1 1 1 € 27.58
4 375619 gasket 6 € 0.00
4 388358 bolt 6 € 0.00
4 1335215 BOLT 6 6 6 € 6.17
5 263750 valve stop 24 24 24 24 € 1.03
6 149867 exhaust valve 6 6 6 6 € 0.00
6 312948 cap 6 6 6 6 € 7.12
7 314539 oil shield 12 12 12 12 € 0.00
8 145173 seal 12 12 12 12 € 3.53
9 263748 spring 12 12 12 12 € 32.00
10 375564 seal 6 6 6 6 € 0.00
10 375565 seal (exhaust valve) 6 6 € 0.00
11 149858 stud (0,33 mm) 12 12 12 12 € 0.00
11 149857 stud 12 12 12 12 € 10.74
12 1307964 ROCKER ARM 12 12 12 12 € 76.80
13 281097 ball 12 12 12 12 € 0.00
14 370150 nut 12 12 12 12 € 0.00
15 375567 bolt (0,95 mm) 10 10 10 10 € 0.00
16 375568 bolt (0,75 mm) 4 4 4 4 € 0.00
17 263847 bolt (0,45 mm) 12 12 12 12 € 0.00
18 388361 spark plug 6 6 6 € 7.07
18 197888 spark plug 6 € 7.07
19 1351991 cylinder head 2 2 € 0.00
19 1306675 cylinder head 2 2 € 0.00
20 375558 inlet valve (0,0889 mm o/s) 6 6 6 6 € 0.00
20 375559 inlet valve (0,394 mm o/s) 6 6 6 6 € 0.00
20 375560 inlet valve (0,76 mm) 6 6 6 6 € 0.00
20 375557 inlet valve 6 6 6 6 € 67.91
21 265512 exhaust valve 6 6 6 6 € 34.87
21 375562 exhaust valve (0,38 mm) 6 € 0.00
21 375563 exhaust valve (0,76 mm) 6 € 0.00
21 254384 exhaust valve 6 6 6 € 37.70
22 263839 valve lifter 12 € 32.03
22 388357 valve lifter 12 12 12 € 53.72
23 369774 push rod 12 € 49.54
23 388356 push rod 12 12 12 € 24.61
24 388350 cylinder head gasket 2 2 2 2 € 0.00
25 164050 grommet 2 2 2 2 € 7.97
26 321734 pcv valve 1 1 1 1 € 10.26
27 379407 fitting 1 1 1 1 € 12.76
28 1317472 manifold (exhaust) 2 2 2 2 € 0.00
29 352903 stud 3 3 3 3 € 6.93
29 370168 stud 3 3 3 3 € 5.85
30 16379 capscrew 12 12 12 12 € 1.62
31 366686 lock 6 6 6 6 € 8.22
32 353307 hose 1 1 1 1 € 51.12
33 325897 clamp 1 1 1 1 € 7.18
34 1350036 BREATHER 1 1 1 1 € 10.85
35 1300152 WASHER 1 1 1 1 € 4.40
36 14761 fitting 1 1 1 1 € 1.26
37 379400 fitting 1 1 1 1 € 97.33
38 379405 clamp 1 1 1 1 € 3.12
39 353199 clamp 1 1 1 1 € 3.46
40 292501 Capscrew 1 1 1 1 € 0.20
41 320156 washer 1 1 1 1 € 0.10
42 186998 bracket 1 1 1 1 € 45.87
43 292680 Washer 1 1 1 1 € 0.10
44 136687 nut 1 1 1 1 € 0.10
45 15162 lockwasher 1 1 1 1 € 0.42
47 1316494 SHIELD 2 a € 74.84
48 1316488 SHIELD 2 a € 6.86
49 171352 lubricant AR AR AR AR € 5.58
1312809 kit-gasket 1 1 1 1 € 181.89
