Footnote

Q1. 6LX 1996 Series Engine
Q2. 7LX 1997 Series Engine
Q3. 8LX 1998 Series Engine
Q4. 9LX 1999 Series Engine

a GM Identification Number on Left Side of Rear
Transmission Housing is 8 Digits
b GM Identification Number on Left Side of Rear
Transmission Housing Starts with "A" Followed by
8 Digits

Products

* All prices are excl. VAT

No. Code Name Q1 Q2 Q3 Q4 Notes Price
No. Code Name q1 q2 q3 q4 notes Price
1 1374296 camshaft 1 1 € 0.00
1 1456111 CAMSHAFT 1 1 € 1049.86
2 1374297 PIN 2 2 2 2 € 32.41
3 375616 chain 1 € 87.68
3 1450792 CHAIN 1 1 1 € 103.33
4 1374300 SPROCKET 1 1 1 1 € 97.83
5 375615 sprocket 1 1 1 1 € 106.34
6 1374301 BOLT 3 3 3 3 € 11.54
7 1374299 BOLT 2 2 2 2 € 3.41
8 1374298 RETAINER 1 1 1 1 € 49.25
9 1454955 BEARING 2 2 2 a € 60.47
9 301955 bushing (position a d) 2 € 0.00
10 1454956 BEARING 1 1 1 a € 123.04
10 301956 bushing (position b) 1 € 0.00
11 301957 bushing (position c) 1 € 0.00
11 1454957 BEARING 1 1 1 b € 102.12
12 1374307 BOLT 2 € 16.70
12 1383257 BOLT 4 4 4 € 6.13
13 263827 stud 2 € 6.96
14 1335240 BOLT 1 € 16.16
15 1389100 WATER PUMP 1 1 1 € 150.80
15 1450553 kit-repair water pump 1 € 188.92
16 263828 gasket 2 2 2 2 € 5.77
17 159977 pin 6 6 6 6 € 5.00
18 1386176 ENGINE OIL PUMP 1 1 1 1 € 309.65
19 375587 fitting 1 1 1 1 € 23.65
20 1386178 DAMPER 1 1 1 1 € 404.08
21 1386180 COVER 1 1 1 1 € 245.22
22 1386179 BOLT 3 3 3 3 € 12.63
23 1377103 BOLT 2 2 2 2 € 13.93
24 1386184 GASKET 1 1 1 1 € 69.29
25 1389104 OIL PAN 1 1 1 1 € 484.20
26 1460757 SCREW 1 1 1 € 21.28
26 388305 gasket 1 1 1 € 7.06
26 1460758 GASKET 1 € 7.12
27 1386183 BOLT 10 10 10 10 € 3.98
28 1360178 NUT 2 2 2 2 € 14.01
29 1377104 SEAL 1 1 1 1 € 46.94
30 1374317 BOLT 6 6 6 6 € 10.49
31 1374315 KIT-GEAR 1 1 1 1 € 215.25
32 1374326 RETAINER 1 1 1 1 € 30.25
33 1377107 SHAFT 1 1 1 1 € 158.68
34 1374313 PLUG 1 1 1 1 € 9.69
35 1374314 BEARING 1 1 1 1 € 125.80
36 1339963 BOLT 2 2 2 2 € 3.48
37 1335494 gasket 1 1 1 € 0.00
37 1460322 GASKET 1 € 8.22
38 369748 washer 10 10 10 10 € 15.12
39 1374108 BOLT 10 10 10 10 € 13.58
40 1320000 OIL FILTER 1 1 1 1 € 8.15
41 1383263 CAP 1 1 1 1 € 4.55
42 130845 clamp 1 1 1 1 € 2.04
43 1451320 SCREEN 1 1 € 42.55
43 1386177 SCREEN 1 1 € 42.55
44 1392547 hose 1 1 1 € 0.00
45 1392548 CLAMP 2 2 2 2 € 4.66
46 1393350 fitting 1 1 1 1 € 38.32
1460768 kit-bearing 1 1 1 1 € 457.75
1454974 bearing set 1 1 1 1 € 0.00
