Footnote

a Crankshaft Includes Standard Bearings
b → U797494C
c U797495C →
1 2 2 2 2 2 2 2 2 2 2 2 2 3 3 3 3 4 4 5 5 5 5 6 7 8 9 10 11 11 12 13 14 14 15 16 17 18 19

Products

* All prices are excl. VAT

No. Code Name Q1 Notes Price
No. Code Name q1 notes Price
1 340874 crankshaft 1 € 0.00
2 161430 kit-crankshaft bearing 1 € 87.55
2 161431 kit-crankshaft bearing 1 € 85.03
2 161429 kit-crankshaft bearing 1 € 77.33
2 161425 kit-crankshaft bearing 1 a € 72.85
3 842799 washer 2 a € 7.76
3 161296 washer 2 € 10.86
4 161297 thrust washer 2 € 10.91
4 842800 washer 2 a € 7.57
5 161433 kit-piston rod (0,51 mm) 1 € 0.00
5 161434 kit-piston rod (0,76 mm) 1 € 0.00
5 161426 kit-piston rod (standard) 1 a € 0.00
5 161432 kit-piston rod (0,25 mm) 1 € 0.00
6 161440 kit-piston rod 4 € 203.99
7 1 € 0.00
8 99663 nut 2 € 1.56
9 161648 bolt 2 € 0.00
10 99668 bearing 1 € 8.29
11 1382564 KIT-PISTON 4 b € 151.58
11 1459456 KIT-PISTON 1 c € 179.36
12 1 € 0.00
13 992003 snapring 2 € 0.96
14 1459457 KIT-PISTON RING 1 c € 99.02
14 1309832 KIT-PISTON RING 4 b € 86.36
15 99610 key 1 € 3.97
16 1305706 GEAR 1 € 113.92
17 1306193 PULLEY 1 € 423.28
18 1306194 BLOCK 1 € 58.36
19 302713 screw 3 € 9.26
