Footnote

a → S/N F006A03039
b S/N F006A03040 →

Products

* All prices are excl. VAT

No. Code Name Q1 Notes Price
No. Code Name q1 notes Price
1 1387255 radiator (oil clutch) 1 € 0.00
1 1387250 radiator (powershift) 1 € 0.00
2 184529 belt tension gauge 1 € 0.00
3 178899 radiator cap 1 € 7.92
4 221733 washer 4 € 0.45
4 15055 nut 4 € 0.17
5 350052 cover 1 € 0.00
6 353310 Clamp 2 € 2.03
7 1302955 hose 1 € 0.00
8 339735 hose 1 € 0.00
9 345454 cap 1 € 3.29
10 345455 outlet assembly 1 € 0.00
11 336550 bushing 1 € 0.68
12 344432 reservoir 1 € 30.69
13 340204 strap 1 € 4.80
14 340203 bracket 1 € 190.66
15 124297 clamp 1 € 6.90
16 320158 washer 4 € 0.45
17 239503 nut 4 € 0.13
17 292681 Lockwasher 6 € 0.14
18 373110 shroud 1 a € 316.88
18 377342 shroud 1 b € 484.09
19 985420 v-belt 1 a € 13.29
19 377333 v-belt 1 b € 17.06
20 16073 screw 4 € 1.35
20 15127 Washer 4 € 0.22
21 1345752 GASKET 1 a € 5.69
22 313221 clamp 1 a € 9.63
22 2050704 hose clamp 1 b € 0.00
23 344373 radiator hose 1 a € 58.65
23 377337 radiator hose 1 b € 48.67
24 119236 clamp 3 € 3.04
25 137852 strap clamp 1 € 0.15
26 12815 drain valve 1 € 4.11
27 220159 Capscrew 2 a € 3.83
27 16814 capscrew 2 a € 1.07
28 352832 elbow 1 a € 0.00
29 344372 radiator hose 1 a € 28.49
29 377336 radiator hose 1 b € 36.80
30 15155 lockwasher 4 a € 0.14
30 292509 Capscrew 4 b € 0.45
30 292681 Lockwasher 4 b € 0.14
30 18510 capscrew 4 a € 1.22
31 353100 fan 1 a € 124.79
31 377331 fan 1 b € 120.13
32 170999 extension 1 a € 0.00
32 161527 adapter 1 b € 21.17
33 227180 screw 1 a € 1.93
33 15127 Washer 1 a € 0.22
34 1374447 PULLEY 1 a € 1463.04
34 1455578 FAN PULLEY 1 b € 147.68
35 320157 washer 4 b € 0.10
36 119236 clamp 1 a € 3.04
36 112989 Hose Clamp 1 b € 2.79
37 1347275 KIT-FAN DRIVE 1 € 711.10
38 1 € 0.00
39 982328 snapring 1 € 3.65
40 1 € 0.00
41 1343174 SCREW 4 € 10.47
42 1 € 0.00
