Q1. 0LX 2000 Series Engine
Q2. 1LX 2001 Series Engine
Q3. 2MY 2002 Series Engine
Q4. 3MY 2003 Series Engine
Q5. 4MY 2004 Series Engine

a → S/N F006V02324A
b S/N F006V02325A →

Products

* All prices are excl. VAT

No. Code Name Q3 Q4 Q5 Q1 Q2 Price
No. Code Name q3 q4 q5 q1 q2 Price
1 1 1 1 € 0.00
1 1501157 short block 1 1 € 0.00
2 1390759 KIT-PISTON 6 6 6 6 6 € 353.25
2 1390760 KIT-PISTON 6 6 6 6 6 € 405.31
3 1390761 KIT-PISTON RING 6 6 6 6 6 € 146.50
3 1390765 KIT-PISTON RING 6 6 6 6 6 € 105.10
4 1360179 piston rod 6 6 6 6 6 € 0.00
5 1360182 BOLT 2 2 2 2 2 € 12.06
6 1330450 NUT 2 2 2 2 2 € 3.05
7 1390770 PISTON ROD BEARING 6 6 6 6 6 € 83.57
7 375580 piston rod bearing (undersize) (0.14 mm) 6 6 6 6 6 € 0.00
8 1460386 CRANKSHAFT 1 1 1 1 1 € 2642.82
9 169718 plug 5 5 5 5 5 € 4.37
10 263842 bolt 10 10 10 10 10 € 12.70
11 1460737 KIT-CRANKSHAFT BEARING 3 3 3 3 3 € 96.05
11 1460738 KIT-CRANKSHAFT BEARING 3 3 3 3 3 € 56.92
12 1390773 KIT-CRANKSHAFT BEARING 1 1 1 1 1 € 167.96
13 1514968 BY-PASS VALVE 1 1 1 € 16.02
13 1358156 VALVE 1 1 € 15.40
14 159977 pin 4 4 4 4 4 € 5.00
15 1374313 PLUG 1 1 1 1 1 € 9.69
16 1335499 PIN 2 2 2 2 2 € 11.62
17 1451319 KEY 1 1 1 1 1 € 12.74
18 1500884 GASKET 1 1 1 1 1 € 8.06
19 274232 plug 5 5 5 5 5 € 0.00
20 375601 pin 1 1 1 1 1 € 2.67
21 1460330 RETAINER 1 1 1 1 1 € 319.55
22 1450555 STUD 2 2 2 2 2 € 16.07
23 1460331 SEAL 1 1 1 1 1 € 89.83
24 375575 bolt 2 2 2 2 2 € 15.18
25 1335490 BOLT 1 1 1 1 1 € 7.52
26 1335226 NUT 1 1 1 1 1 € 1.67
27 1331341 PLUG 3 3 3 3 3 € 13.14
28 1358079 PLUG 3 3 3 3 3 € 9.74
28 388302 plug (rh) 2 2 2 2 2 € 5.63
