Footnote

KEY:
Q1. 0XL 2000 Series Engine
Q2. 1LX 2001 Series Engine
Q3. 2MY 2002 Series Engine
Q4. 3MY 2003 Series Engine
Q5. 4MY 2004 Series Engine

a Quantity is listed for both heads
b → S/N F006V02324
c S/N F006V02325

Products

* All prices are excl. VAT

No. Code Name Q1 Q2 Q3 Q4 Q5 Notes Price
No. Code Name q1 q2 q3 q4 q5 notes Price
1 1386185 COVER 1 1 1 1 1 € 97.43
2 1389102 COVER 1 1 1 1 1 € 126.64
3 1374290 CAP 1 1 1 1 1 € 23.26
4 1450869 DISTRIBUTOR 1 1 1 1 1 € 429.08
5 1334423 GASKET 1 1 1 1 1 € 2.28
6 1374288 GROMMET 3 3 3 3 3 € 13.58
7 1331341 PLUG 1 1 1 1 1 € 13.14
8 1641492 SPARK PLUG 6 6 6 6 6 € 6.98
8 1452376 SPARK PLUG 6 6 6 6 6 € 7.25
9 1389093 bolt 8 8 8 8 8 € 14.86
10 1383904 GROMMET 6 6 6 6 6 € 13.54
11 1374289 BOLT 6 6 6 6 6 € 3.08
12 1386186 intake manifold (intake) 1 1 1 1 1 € 0.00
13 1386187 kit-gasket 1 1 1 1 1 € 95.59
14 1374293 GASKET 2 2 2 2 2 € 37.81
15 1377792 BOLT 10 10 10 10 10 a € 9.63
16 1377793 BOLT 4 4 4 4 4 a € 14.06
17 1377794 BOLT 10 10 10 10 10 a € 4.57
18 1471559 VALVE LIFTER 12 12 12 12 12 € 135.89
19 1389050 GUIDE 2 2 2 2 2 € 52.32
20 1389051 BOLT 4 4 4 2 2 € 75.58
21 1386189 PUSH ROD 12 12 12 12 12 € 22.93
22 1460333 KIT-GASKET 1 1 € 273.64
22 1386190 CYLINDER HEAD GASKET 2 2 2 € 54.86
23 1386191 IGNITION COIL 1 1 1 1 1 € 260.19
24 220159 Capscrew 2 2 5 5 5 € 3.83
25 1380802 EXHAUST MANIFOLD 1 1 1 € 1569.47
25 1502741 exhaust manifold 1 1 € 0.00
26 352952 heat shield 1 1 1 € 64.39
26 1529010 HEAT SHIELD 1 1 € 56.61
27 1316488 SHIELD 2 2 2 2 2 € 6.86
28 1316494 SHIELD 2 2 2 2 2 € 74.84
29 1384349 STUD 6 6 6 € 102.11
30 1383257 BOLT 12 12 12 12 12 € 6.13
31 1383241 SUPPORT 1 1 1 1 1 € 37.07
32 15154 lockwasher 4 4 4 4 4 € 0.10
33 133469 capscrew 4 4 4 4 4 € 0.23
34 379407 fitting 1 1 1 1 1 € 12.76
35 1510649 DIPSTICK 1 1 1 € 113.12
36 369139 dipstick tube 1 1 1 € 89.95
36 1514915 dipstick tube 1 1 € 0.00
37 133696 clamp 1 1 1 1 1 € 5.75
38 1383237 GASKET 1 1 1 1 1 € 1.82
39 1383211 PLATE 1 1 1 1 1 € 475.89
40 1383213 GASKET 1 1 1 1 1 € 3.08
41 1383239 SPACER 1 1 1 1 1 € 147.91
42 1333806 GASKET 1 1 1 1 1 € 15.55
43 16836 capscrew 7 7 7 7 7 € 0.65
44 15155 lockwasher 10 10 10 10 10 € 0.14
45 16394 capscrew 1 1 1 1 1 € 0.23
46 1371229 WATER OUTLET 1 1 1 1 1 € 35.89
47 1450643 THERMOSTAT 1 1 1 1 1 € 38.07
48 1330725 GASKET 1 1 1 1 1 € 3.64
49 16598 Capscrew 2 2 2 2 2 € 1.00
