Footnote

a 3KM 1993 and 5LM 1995 Series Engine
b → S/N F006A07082
c → S/N F006A11558Z
d S/N F006A11559Z →

Products

* All prices are excl. VAT

No. Code Name Q1 Notes Price
No. Code Name q1 notes Price
1 1374109 THERMOSTAT 1 44.10
2 1371229 WATER OUTLET 1 35.89
3 1374110 SEAL 1 24.50
4 375597 bolt 2 11.20
5 1374111 INTAKE MANIFOLD 1 696.11
6 388308 bolt 1 2.48
7 388359 plug 1 16.25
8 1314381 TEMPERATURE SENDER 1 43.42
9 375598 stud 4 0.00
10 2 0.00
11 1334423 GASKET 1 2.28
12 1335497 clamp 1 18.60
13 1374113 GASKET 1 0.92
14 1374112 cover (egr valve) 1 16.82
15 375622 distributor (ffigure 4-31) 1 b 0.00
15 1371235 distributor 1 a 0.00
16 1383904 GROMMET 6 13.54
17 1375925 spark plug 6 5.90
18 1327907 support 1 0.00
19 370169 kit-screw 3 2.82
20 1374324 support 1 79.04
21 1374291 cover (lh) 1 0.00
21 1374292 cover (rh) 1 0.00
22 1374293 GASKET 2 37.81
23 1374288 GROMMET 3 13.58
24 1374289 BOLT 6 3.08
25 1374290 CAP 1 23.26
26 321734 pcv valve 1 10.26
27 1377792 BOLT 10 9.63
28 1377793 BOLT 4 14.06
29 1377794 BOLT 12 4.57
30 1333542 gasket (cylinder head) 2 0.00
31 388356 push rod 12 24.61
34 136749 Screw 2 0.23
35 320157 washer 2 0.10
36 1337871 HOSE 1 30.20
37 1374324 support 1 79.04
38 1350036 BREATHER 1 10.85
39 1300152 WASHER 1 4.40
40 14761 fitting 1 1.26
41 292681 Lockwasher 2 0.14
42 352952 heat shield 1 64.39
43 1316488 SHIELD 2 6.86
44 1316494 SHIELD 2 74.84
45 366686 lock 6 8.22
46 379400 fitting 1 97.33
47 379405 clamp 1 3.12
48 353199 clamp 1 3.46
49 1304392 WASHER 12 0.78
50 15162 lockwasher 1 0.42
51 1369485 COVER 1 0.79
52 1510649 DIPSTICK 1 c 113.12
53 369139 dipstick tube 1 89.95
53 288394 sealant AR 0.00
54 1317472 manifold (exhaust) 2 0.00
55 16379 capscrew 11 1.62
56 352903 stud 6 6.93
57 1335241 PLUG 1 5.56
58 1371233 bolt 4 21.02
59 1378932 stud 1 0.00
60 133696 clamp 1 5.75
61 186998 bracket 1 45.87
62 239503 nut 2 0.13
