a → U503404S
b → U690784A
c U502405S →
d U690785A →

Products

* All prices are excl. VAT

No. Code Name Q1 Notes Price
No. Code Name q1 notes Price
1 1306137 oil pan 1 € 0.00
2 266465 insert 2 € 15.62
3 377976 plug 2 € 12.10
4 1306374 O-RING 2 € 3.88
5 1344913 gasket 1 € 0.00
6 1306368 SCREW 1 € 9.96
7 1454315 thimble 2 € 10.04
8 1307880 NUT 1 € 11.19
10 1318965 screw 6 c € 6.38
10 1307878 screw 6 a € 0.00
11 386459 screw 12 € 1.76
12 1306140 PIPE 1 € 153.75
13 1344921 GASKET 1 € 2.21
14 1307879 SCREW 2 € 2.00
15 1306141 tube 1 b € 0.00
15 1385702 TUBE ASSY 1 d € 91.00
16 1306328 snapring 1 € 9.96
17 1385701 DIPSTICK 1 d € 22.62
17 1342594 dipstick 1 b € 0.00
18 1306942 frame 1 € 0.00
19 1306146 BRACKET 1 € 23.07
20 1307881 screw 1 € 3.56
21 296418 washer 1 € 1.33
22 1306147 CLIP 1 € 10.50
23 1306148 PLATE 1 € 13.47
24 1307882 SCREW 1 € 1.12
25 1307883 SCREW 1 € 1.44
26 1514429 nut 2 € 0.54
27 1307885 WASHER 1 € 1.09
28 1377908 PLUG 1 € 9.52
29 1306358 screw 2 € 3.50
30 1306176 bracket 1 € 0.00
31 1307886 screw 1 € 9.52
32 1307887 NUT 1 € 0.91
33 293780 lockwasher 1 € 0.33
34 245781 spacer 1 € 7.36
35 1306039 ENGINE OIL PUMP 1 € 313.13
36 1380755 SHAFT 1 € 104.93
37 1306040 GEAR 1 € 328.92
38 1306041 BUSHING 1 € 20.73
39 385847 washer 1 € 7.66
40 328047 snapring 1 € 1.30
41 1306362 SCREW 3 € 1.95
42 1306042 PIPE 1 € 195.98
43 1306363 O-RING 2 € 10.01
44 1306043 FLANGE 1 € 22.23
45 1315494 relief valve 1 € 0.00
46 301749 plunger 1 € 9.06
47 1306047 spring 1 € 0.00
48 301751 cap 1 € 19.42
1371723 kit-gasket 1 € 166.78
