Footnote

Q1. 6KM 1986 Series Motor
Q2.7KM 1987 Series Motor
Q3.8KM 1988 Series Motor
Q4.9KM 1989 Series Motor

a S/N F006A11558Z, b S/N F006A11559Z

Products

* All prices are excl. VAT

No. Code Name Q2 Q3 Q4 Q1 Notes Price
No. Code Name q2 q3 q4 q1 notes Price
1 1303792 cylinder block 1 1 1 € 0.00
1 306770 cylinder block 1 € 0.00
2 169718 plug 8 8 8 8 € 4.37
3 1450941 PIN 4 4 4 4 € 16.50
4 159977 pin 4 4 4 4 € 5.00
5 1335499 PIN 2 2 2 2 € 11.62
6 349378 plug 2 2 2 2 € 4.95
7 150879 fitting 1 1 1 1 € 3.20
8 388302 plug (rh) 2 2 2 € 5.63
9 1358156 VALVE 1 1 1 1 € 15.40
10 263788 plug 1 1 1 1 € 0.00
11 15962 fitting 1 € 4.86
12 274232 plug 2 2 2 2 € 0.00
13 375590 gasket 1 1 1 1 € 5.80
14 375589 pointer 1 1 1 1 € 6.11
15 1690267 oil seal 1 1 1 1 € 0.00
15 1335059 cover 1 1 1 1 € 0.00
16 370169 kit-screw 10 10 10 10 € 2.82
17 263826 stud 1 1 1 1 € 0.00
18 263827 stud 1 1 1 1 € 6.96
18 185768 capscrew 1 1 1 1 € 1.35
19 177461 capscrew 1 1 1 1 € 0.76
20 133469 capscrew 6 6 6 6 € 0.23
20 369748 washer 6 6 6 6 € 15.12
20 381355 water pump 1 1 1 1 € 179.92
21 263828 gasket 2 2 2 2 € 5.77
22 388353 kit-gasket 1 1 1 € 26.95
22 375596 gasket 1 1 1 € 16.42
23 221499 capscrew 2 2 2 2 € 0.93
24 246479 water outlet 1 1 1 1 € 0.00
25 1330725 GASKET 1 1 1 1 € 3.64
26 231522 thermostat 1 1 1 1 € 11.59
27 375593 manifold 1 1 1 1 € 0.00
28 375595 plug 1 1 1 1 € 0.00
29 375594 guard 1 1 1 1 € 0.00
30 1335213 STUD 4 4 4 4 € 0.86
31 375597 bolt 4 4 4 4 € 11.20
32 355905 bolt 4 4 4 4 € 0.00
33 375599 stud 3 3 3 3 € 0.00
34 375598 stud 1 1 1 1 € 0.00
35 375587 fitting 1 1 1 1 € 23.65
36 14349 Fitting (Pipe Plug) 1 1 1 1 € 1.23
37 388308 bolt 4 4 4 € 2.48
38 15962 fitting 1 1 1 € 4.86
39 388359 plug 1 1 1 € 16.25
39 150879 fitting 1 € 3.20
40 263728 bracket (rear) 1 1 € 0.00
41 1320000 OIL FILTER 1 1 1 1 € 8.15
42 369139 dipstick tube 1 1 1 1 € 89.95
42 288394 sealant AR AR AR AR € 0.00
43 1510649 DIPSTICK 1 1 1 1 a € 113.12
44 133696 clamp 1 1 1 1 € 5.75
45 178297 degreaser AR AR AR AR € 0.00
381352 kit-gasket 1 1 1 1 € 31.19
1312809 kit-gasket 1 1 1 1 € 181.89
