Footnote

a → 3/1998
b → S/N F006A08446
c → S/N F006A08488
d S/N F006A08447 →

Products

* All prices are excl. VAT

No. Code Name Q1 Notes Price
No. Code Name q1 notes Price
1 1387255 radiator (oil clutch) 1 a € 0.00
1 1456899 RADIATOR 1 € 2102.82
2 1377736 SPACER 1 b € 132.18
3 119236 clamp 4 € 3.04
4 178899 radiator cap 1 € 7.92
5 353310 Clamp 2 € 2.03
6 15055 nut 4 € 0.17
6 221733 washer 4 € 0.45
7 350052 cover 1 € 0.00
8 137852 strap clamp 1 € 0.15
9 339735 hose 1 € 0.00
10 345454 cap 1 € 3.29
11 345453 outlet (reservoir) 1 € 5.63
12 336550 bushing 1 € 0.68
13 344432 reservoir 1 € 30.69
14 1302955 hose 1 € 0.00
15 373109 shroud 1 € 444.09
16 16073 screw 4 € 1.35
16 15127 Washer 4 € 0.22
17 148891 fan 1 € 180.20
18 340204 strap 1 € 4.80
19 340203 bracket 1 € 190.66
20 124297 clamp 1 € 6.90
21 320158 washer 4 € 0.45
22 292681 Lockwasher 6 € 0.14
23 1377754 RADIATOR HOSE 1 € 70.77
24 12815 drain valve 1 € 4.11
25 344366 radiator hose 1 € 31.64
26 1377773 bracket 1 c € 0.00
27 1377750 pulley 1 c € 81.47
28 1377735 WATER PUMP PULLEY 1 c € 206.06
29 1377752 TENSIONER 1 c € 171.94
30 136681 capscrew 4 € 0.23
31 292681 Lockwasher 8 € 0.14
32 287860 Capscrew 4 € 0.65
34 18527 capscrew 4 € 2.24
35 18547 Capscrew 2 € 4.62
36 292524 capscrew 1 € 1.52
37 316826 nut 1 € 2.31
38 1377774 WASHER 1 c € 67.98
39 16634 capscrew 3 € 1.07
40 16805 Capscrew 3 € 0.52
41 1377781 SPACER 1 c € 76.78
42 1377795 SPACER 1 c € 82.20
43 1377760 pulley 1 b € 0.00
43 1380309 PULLEY 1 d € 870.53
44 1377761 BELT 1 c € 59.63
45 1 € 0.00
46 c1377745 hub 1 € 0.00
47 c1377749 shaft 1 € 0.00
48 c128469 ball bearing 2 € 0.00
49 12928 snapring 1 € 1.76
50 c172885 spacer 1 € 0.00
50 c257291 adhesive AR € 0.00
51 c131357 snap ring 2 € 0.00
52 18549 capscrew 1 € 6.56
53 239503 nut 4 € 0.13
33 292682 lockwasher 12 € 0.19
